TYPICAL VALUES FOR 52M SERIES

Model

number

Output

V/A

RECTANGULAR PULSE

SINEWAVE

DC saturation current Isat A

Max rms current Irms A

Peak current

A

Price GBP

*

Droop

%/ms

Rise time

ns

I-t Capability

3db bandwidth

Ipeak/f

A/Hz

No bias mA s

With bias mA s

Lf

Hz

HF

MHz

52M0100

0.10

0.50

20

600

1100

0.7

20

3

2.0

100

5000

POA

52M0500

0.50

10.0

20

25

45

20

20

0.15

2.0

20

1000

POA

52M1000

1.00

40.0

20

6

11

80

20

0.03

2.0

10

500

POA
