13 Series Current Transformers

Models 13D, 13G and 13W

13-series
Model_13





TYPICAL VALUES MODELS 13D, 13G and 13W





Model

 number

Output

V/A

RECTANGULAR PULSE

SINEWAVE

DC saturation current Isat A

Max rms current Irms A

Peak current Ipeak A

Price GBP

*

Droop %/ms

Rise time ns

I-t capability

3db Bandwidth

Ipeak/f A/Hz

No bias mA s

With bias  mA s

lf Hz

hf MHz

13E0020

0.020

1.4

140

1600

2900

2.2

3

10

22

200

25000

POA

13E0050

0.050

3.3

40

660

1200

5.3

10

4.1

22

100

10000

POA

13G0050

0.050

0.25

40

1200

2200

0.5

10

8

3

100

10000

POA

13W0050

0.050

0.06

40

1200

2200

0.1

10

3

0.25

100

10000

POA

13E0100

0.10

10

16

220

400

16

25

1.4

22

60

5000

POA

13G0100

0.10

1

16

400

700

1.6

25

2.5

3

60

5000

POA

13W0100

0.10

0.15

16

300

540

0.3

25

2

0.25

60

5000

POA

13E0200

0.20

37

14

60

110

60

30

0.38

22

33

2500

POA

13G0200

0.20

4

14

100

200

10

30

0.7

3

33

2500

POA

13W0200

0.20

0.6

14

40

70

1

30

0.25

0.25

33

2500

POA

13E0500

0.50

220

10

10

18

360

40

0.062

22

14

1000

POA

13G0500

0.50

20

10

15

30

35

40

0.12

3

14

1000

POA

13W0500

0.50

3

10

7

13

5

40

0.04

0.25

14

1000

POA

13E1000

1.0

880

7

2.5

4.5

1400

60

0.016

22

7

500

POA

13G1000

1.0

70

7

4

7

130

60

0.03

3

7

500

POA

13W1000

1.0

12

7

4

7

30

60

0.02

0.25

7

500

POA

13W5000

5.0

320

4

0.12

0.2

550

100

0.0004

0.25

2

50

POA

* POA. Please contact us for our latest price on the transformer of interest to you.

Updated    December 2018
